Noted, why 470 ohm with white and 270 with blue, what is the difference between them. moreover, this resistor would attach with each LED or each sereies, pls clear.

us000 (us000) 2009-07-03 10:04:00 +0600 #22

Blue requires more voltage than white.
so a smaller resistor was used for blue.
these are not calculated values, just by hit n trial.

us000 (us000) 2009-07-03 10:06:00 +0600 #23

attach one terminal of the resistor directly where the original bulbs are placed(on the meter)
and the other terminal of led to the resistor, and then to the other terminal on the meter.

and plz take care of the +ve and -ve of the meter, as the LEDs are polarity sensitive.

sunny234 (sunny234) 2009-07-03 11:06:00 +0600 #24

nice work done.

us000 (us000) 2009-07-03 15:47:00 +0600 #25

why the pics are not uploading properly?

yasir_01 (yasir_01) 2009-07-03 17:08:00 +0600 #26

NYC
MASHALLAH

us000 (us000) 2009-07-03 18:11:00 +0600 #27

also changed the power windows AUTO led from green to Blue

smartyangel (smartyangel) 2009-07-03 18:25:00 +0600 #28

(Y)(Y)(Y)(Y)(Y)(Y) GooD Diy mate and ...... keep Us update....with ur new diy's......

Keep it up (Y)(Y)

us000 (us000) 2009-07-04 16:28:00 +0600 #29

us000 (us000) 2009-07-04 16:30:00 +0600 #30

SER_GTR (SER_GTR) 2009-07-04 16:36:00 +0600 #31

Nice Progress..But That Diminish Thing On Some Parts Of Meter And Brighter On Some Side Is Due To The Light Angles Of LED.....!!! You Need A Wide Angle LED With Nothing In B/w To Get Perfect Glowing Meter...!! You Need To Put LED's All Around To Overcome This ....!! Overall...Nice Work Done (y)

us000 (us000) 2009-07-04 16:39:00 +0600 #32

yup, thsat time i had only typical leds, but now i m working on rear LED lites using the wide angle LEDs.

thanx bro.
