if one can find their cars original alignment spec from the repair/service manuals - they can follow that to get the exact detail I mentioned above.

But the person has to make sure they are looking at RHD or LHD data - both are different. The xHD is for both vehicle and country.

meaning LHD vehicle in RHD country will need to be modified to align to RHD roads (they have opposite road crown)

[xzap042]

I would love to know those guys in isb.

[capsat]

[capsat]

please flag any duplicates for deletion

[capsat]

[capsat]

[capsat]

@VCheng @Xulfiqar
please explain this cold loop phenomena

[capsat]

[capsat]

[capsat]

[VCheng]

Incorrect diagram. The ring gaps are always staggered, and the gap itself carefully adjusted by a special grinder tool to ensure good compression.

[Xulfiqar]

Ive had great luck with my oldschool diamond files

[VCheng]

You are truly an exception. How many file the edges at the required angle and doublecheck the end gap clearance for each ring within the bore before installing them on the piston?

[Xulfiqar]

Normal ashraf ul makhlooqaat do what you wrote

Rest dont.

[syncview]

a quick touch at an angle grinder works well too specially for NPR top rings

[capsat]

Illustration is for ring placement information only
How it should actually be done is another story

[Xulfiqar]

should I post types of oil ring packs?

[capsat]

why not? please go ahead.

[capsat]

[capsat]

clutch system
