HONDA CITY 2001 Meter Gaugues going Crazy

syedfaizan1 (Faizan) 2018-09-12 06:13:18 +0500 #1

Hi salam everyone. i have honda city 2003 Model means 2001 Shape. I have experiencing some issues from 2 3 days. The meter gaugues are going crazy when i give high acceleration like till 7000 RPM. When i switch on the Parking light the petrol needle goes up and stays up but in real the fuel is low in car and when give acceleration for high then all needels goes crazy like RPM going up down,. Temperate doing up Down, and Hazards blinking, All lights in meter blinking . means ajeeb hojata hai sab. please bataen koi kya masla hai. mene Electrician c pcoha tha or dikahya b tha he said k is k meter me masla hai Wiring sai hai Engine c but i am confident on him. Anyone ever face such issue? please ntoe GADI chalnnay me sai hai koi jhatka koi problem nai hai Smooth chal rai hai ek dum.

Hassan1991 (Electrical Engineer ) 2018-09-12 06:22:57 +0500 #2

He's right.
Sign of shortage.

syedfaizan1 (Faizan) 2018-09-12 06:28:30 +0500 #3

to meter Kholna Paryga bro? Meter me Shortage hai? ya somwhere else ?

Hassan1991 (Electrical Engineer ) 2018-09-12 06:56:52 +0500 #4

Looks like in meter. First check the meter wiring then anything else.

syedfaizan1 (Faizan) 2018-09-12 16:47:33 +0500 #5

Ok bro me check karvata hun Meter wiring. please note yeh masla tab shoro hota jab me Parking on karun werna masla nai hota day time me. only at night when i open parking light or headlights .

syedfaizan1 (Faizan) 2018-09-12 16:48:12 +0500 #6

By the way any more suggestions from Senior pakwheelers ?

ab6666 (Abdullah) 2018-09-12 19:29:13 +0500 #7

Could be a bad ground issue.

syedfaizan1 (Faizan) 2018-09-13 17:27:17 +0500 #8

Guys issue Resolved. The guy put one Wrie on back side of meter and attach it with Body and issue got resolved.

syedfaizan1 (Faizan) 2018-09-15 06:35:56 +0500 #9

Guys there is one issue i am facing. The Speed Meter needle is behaving odd. The needle is going up and down not still . means bht hil rahi hai not stable and the sound is coming from back side of meter place Goon goon goon seems like the Cable is not fitted properly. i will ask that meter guy to fit the cable properly again and put it some oil

Hassan1991 (Electrical Engineer ) 2018-09-15 14:40:02 +0500 #10

If it's cable driven then cable is not fitted properly.

syedfaizan1 (Faizan) 2018-09-17 06:58:13 +0500 #11

You were right bro. The cable was in Bad Shape. i bought new cable of honda city Cost me 400 Rs installed and issue resolved.

Hassan1991 (Electrical Engineer ) 2018-09-17 07:41:20 +0500 #12

Great.

syedfaizan1 (Faizan) 2018-09-17 07:49:06 +0500 #13

I bought the new Cable 380 Rs ki. put it some WD40 in that as well and in the meter motor so there should be no resistant in any way and then installed it. Cleaned the meter as well from inside and now its working fine and shining like new Meter

syedfaizan1 (Faizan) 2018-09-17 07:51:12 +0500 #14
